پایانه فروش Verifone مدل Vx820 Duet

 صفحه نمایش رنگی این مدل 3.5 اینچی و لمسی است. حافظه این مدل 160 مگابایت و قابل ارتقا تا 500 مگابایت است.





Verifone Vx820 DUET
Processor 400 MHz ARM11 32-bit RISC processor
Memory

160 MB (128 MB of Flash, 32 MB of SDRAM) standard,
can exceed up to 500 MB

Display

240×320 pixel color TFT (QVGA) supports
up to 26 lines x 26 characters
8 soft-function keys
4 screen-addressable keys via touch screen

Magnetic Card Reader

Triple track (tracks 1, 2, 3), high coercivity,
bi-directional

Primary Smart Card

ISO 7816, 1.8V, 3V, 5V; synchronous and
asynchronous cards; EMV Approved

SAM Card Reader   3 Security Access Modules (SAMs)
Keypad

3×4 numeric keypad, plus screen-addressable keys
can be simulated on touch screen

Peripheral Ports

USB host and RS-232 to support peripheral devices
Telco and Ethernet ports to support communications

Printer

Integrated thermal printer with graphics capabilities,
18 lines per second, 24 or 32 columns, standard
paper roll 58 mm (2.25 in.) x 25M, single ply

Modem

Standard 56 kbps modem Bell 103/212a, CCITT V.21/
V.22/V.22bis/V.32/V.32bis (300/1200/2400/9600/
14400/33.6/56 and HC FastConnect for 1200bps)

Protocols

Application selects between asynchronous protocols
(Visa 1, Visa 2 and others) and synchronous
protocols (including ISO 8583/SDLC)

Security

3DES encryption, Master/Session and DUKPT
key management; VeriShield file authentication;
PCI PTS 3.0 approved

Physical

Length: 178mm (7.01in.); Width: 98mm (3.86in.);
Height: 109mm (4.3in.); Weight: terminal, 735g
(1.62lbs.)
Full shipping, 1800g (3.96lbs.)

Environmental

0° to 50° C (32° to 122° F) operating temperature;
5% to 90% relative humidity, non-condensing

Voltage

AC input 100 – 240 VAC, 50/60 Hz;
DC output 8.6 – 9.4 VDC, 4.0 Amp

Contactless Applications

MasterCard PayPass M/Chip | MasterCard PayPass
MagStripe | Visa payWave MSD | Visa payWave
qVSDC | Discover Zip | American Express
ExpressPay | Pass-through access to ISO 14443-4
| and MiFare cards, for direct host | terminal-based
application access | Secure SoftSAM protects |
contactless keys | Hardware SAM optional
